Welcome to FragmentColor

JavaScript

npm install fragmentcolor

import init, { Renderer, Shader, Pass, Frame } from "fragmentcolor";

async function start() {
// Initializes the WASM module
await init();

// Initializes a renderer and a target compatible with the given canvas
const canvas = document.getElementById("my-canvas");
const renderer = new Renderer();
const target = await renderer.createTarget(canvas);

// You can pass the shader as a source string, file path, or URL:
const circle = new Shader("./path/to/circle.wgsl");
const triangle = new Shader("https://fragmentcolor.org/shaders/triangle.wgsl");
const shader = new Shader(`
28 collapsed lines
  struct VertexOutput {
      @builtin(position) coords: vec4<f32>,
  }

  struct MyStruct {
      my_field: vec3<f32>,
  }

  @group(0) @binding(0)
  var<uniform> my_struct: MyStruct;

  @group(0) @binding(1)
  var<uniform> my_vec2: vec2<f32>;

  @vertex
  fn vs_main(@builtin(vertex_index) in_vertex_index: u32) -> VertexOutput {
      const vertices = array(
          vec2( -1., -1.),
          vec2(  3., -1.),
          vec2( -1.,  3.)
      );
      return VertexOutput(vec4<f32>(vertices[in_vertex_index], 0.0, 1.0));
  }

  @fragment
  fn fs_main() -> @location(0) vec4<f32> {
      return vec4<f32>(my_struct.my_field, 1.0);
  }
`);

// The library binds and updates the uniforms automatically
shader.set("my_struct.my_field", [0.1, 0.8, 0.9]);
shader.set("my_vec2", [1.0, 1.0]);

// One shader is all you need to render
renderer.render(circle, target);

// But you can also combine multiple shaders in a render Pass
const rpass = new Pass("single pass");
rpass.addShader(circle);
rpass.addShader(triangle);
rpass.addShader(shader);
renderer.render(rpass, target);

// Finally, you can combine multiple passes in a Frame
const frame = new Frame();
frame.addPass(rpass);
frame.addPass(new Pass("GUI pass"));
renderer.render(frame, target);

// To animate, simply update the uniforms in a loop
function animate() {
  circle.set("position", [0.0, 0.0]);
  renderer.render(frame, target);
  requestAnimationFrame(animate);
}
animate();
}

start();

Python

pip install fragmentcolor rendercanvas glfw

  from fragmentcolor import Renderer, Shader, Pass, Frame
  from rendercanvas.auto import RenderCanvas, loop

  # Initializes a renderer and a target compatible with the given canvas
  canvas = RenderCanvas(size=(800, 600))
  renderer = Renderer()
  target = renderer.create_target(canvas)

  # You can pass the shader as a source string, file path, or URL:
  circle = Shader("./path/to/circle.wgsl")
  triangle = Shader("https://fragmentcolor.org/shaders/triangle.wgsl")
  shader = Shader("""
28 collapsed lines
  struct VertexOutput {
      @builtin(position) coords: vec4<f32>,
  }

  struct MyStruct {
      my_field: vec3<f32>,
  }

  @group(0) @binding(0)
  var<uniform> my_struct: MyStruct;

  @group(0) @binding(1)
  var<uniform> my_vec2: vec2<f32>;

  @vertex
  fn vs_main(@builtin(vertex_index) in_vertex_index: u32) -> VertexOutput {
      const vertices = array(
          vec2( -1., -1.),
          vec2(  3., -1.),
          vec2( -1.,  3.)
      );
      return VertexOutput(vec4<f32>(vertices[in_vertex_index], 0.0, 1.0));
  }

  @fragment
  fn fs_main() -> @location(0) vec4<f32> {
      return vec4<f32>(my_struct.my_field, 1.0);
  }
  """)

  # The library binds and updates the uniforms automatically
  shader.set("my_struct.my_field", [0.1, 0.8, 0.9])
  shader.set("my_vec2", [1.0, 1.0])

  # One shader is all you need to render
  renderer.render(shader, target)

  # But you can also combine multiple shaders in a render Pass
  rpass = Pass("single pass")
  rpass.add_shader(circle)
  rpass.add_shader(triangle)
  rpass.add_shader(shader)
  renderer.render(rpass, target)

  # Finally, you can combine multiple passes in a Frame
  frame = Frame()
  frame.add_pass(rpass)
  frame.add_pass(Pass("GUI pass"))
  renderer.render(frame, target)

  # To animate, simply update the uniforms in a loop
  @canvas.request_draw
  def animate():
      circle.set("position", [0.0, 0.0])
      renderer.render(frame, target)

  loop.run()

Rust

use fragmentcolor::{Renderer, Shader, Pass, Frame};
use pollster::block_on;

fn main() -> Result<(), Box<dyn std::error::Error>> {
  block_on(async {
      // Initializes a renderer and a target (offscreen example here)
      let renderer = Renderer::new();
      let target = renderer.create_texture_target([800, 600]).await?;

      // You can pass the shader as a source string, file path, or URL:
      let circle = Shader::new("./path/to/circle.wgsl")?;
      let triangle = Shader::new("https://fragmentcolor.org/shaders/triangle.wgsl")?;
      let wgsl = r#"
28 collapsed lines
struct VertexOutput {
  @builtin(position) coords: vec4<f32>,
}

struct MyStruct {
  my_field: vec3<f32>,
}

@group(0) @binding(0)
var<uniform> my_struct: MyStruct;

@group(0) @binding(1)
var<uniform> my_vec2: vec2<f32>;

@vertex
fn vs_main(@builtin(vertex_index) in_vertex_index: u32) -> VertexOutput {
  const vertices = array(
      vec2( -1., -1.),
      vec2(  3., -1.),
      vec2( -1.,  3.)
  );
  return VertexOutput(vec4<f32>(vertices[in_vertex_index], 0.0, 1.0));
}

@fragment
fn fs_main() -> @location(0) vec4<f32> {
  return vec4<f32>(my_struct.my_field, 1.0);
}
"#;
      let mut shader = Shader::new(wgsl)?;

      // The library binds and updates the uniforms automatically
      shader.set("my_struct.my_field", [0.1f32, 0.8, 0.9])?;
      shader.set("my_vec2", [1.0f32, 1.0])?;

      // One shader is all you need to render
      renderer.render(&shader, &target)?;

      // But you can also combine multiple shaders in a render Pass
      let mut rpass = Pass::new("single pass");
      rpass.add_shader(&circle);
      rpass.add_shader(&triangle);
      rpass.add_shader(&shader);
      renderer.render(&rpass, &target)?;

      // Finally, you can combine multiple passes in a Frame
      let mut frame = Frame::new();
      frame.add_pass(rpass);
      frame.add_pass(Pass::new("GUI pass"));
      renderer.render(&frame, &target)?;

      // To animate, simply update the uniforms in a loop
      for i in 0..60 {
          circle.set("position", [0.0f32, i as f32])?;
          renderer.render(&frame, &target)?;
      }

      Ok(())
  })
}

Swift

Work in progress

Swift bindings are not yet available; implementation is in the works.

import FragmentColor
import SwiftUI

struct ShaderView: View {

  @State private var mousePos = CGPoint(x: 0, y: 0)
  let renderer: FragmentColor.Renderer
  let target: FragmentColor.Target
  let circle: Shader

  init() {
      let canvas = MetalCanvasView() // Your Metal-backed view

      renderer = FragmentColor.Renderer()
      target = renderer.createTarget(canvas)

      circle = Shader("circle.wgsl")!
      circle.setUniform("circle.radius", 200.0)
      circle.setUniform("circle.color", SIMD4<Float>(1.0, 0.0, 0.0, 0.8))
      circle.setUniform("circle.border", 20.0)
  }

  var body: some View {
      CanvasRepresentation()
          .gesture(DragGesture(minimumDistance: 0)
              .onChanged { value in
                  mousePos = value.location
              }
          )
          .onAppear(perform: animate)
  }

  func animate() {
      circle.setUniform("circle.position", SIMD2<Float>(
          Float(mousePos.x),
          Float(mousePos.y)
      ))
      renderer.render(circle, to: target)

      DispatchQueue.main.asyncAfter(deadline: .now() + 1/60) {
          animate()
      }
  }

}

struct CanvasRepresentation: NSViewRepresentable {

  func makeNSView(context: Context) -> some NSView {
      let view = MetalCanvasView()
      view.wantsLayer = true
      return view
  }

  func updateNSView(_ nsView: NSViewType, context: Context) {}

}

Kotlin

Work in progress

Kotlin/Android bindings are not yet available; implementation is in the works.

import androidx.compose.foundation.Canvas
import androidx.compose.foundation.gestures.detectDragGestures
import androidx.compose.runtime.*
import androidx.compose.ui.Modifier
import fragmentcolor.FragmentColor
import fragmentcolor.Shader

@Composable
fun ShaderCanvas() {
  var mousePos by remember { mutableStateOf(Offset.Zero) }
  val renderer = remember { FragmentColor.Renderer() }
  val target = remember { renderer.createTarget(canvas) }
  val circle = remember { Shader("circle.wgsl") }.apply {
      setUniform("circle.radius", 200.0f)
      setUniform("circle.color", floatArrayOf(1.0f, 0.0f, 0.0f, 0.8f))
      setUniform("circle.border", 20.0f)
  }

  LaunchedEffect(Unit) {
      while (true) {
          withFrameNanos {
              circle.setUniform("circle.position", floatArrayOf(
                  mousePos.x.toFloat(),
                  mousePos.y.toFloat()
              ))
              renderer.render(circle, target)
          }
      }
  }

  Canvas(
      modifier = Modifier.detectDragGestures { change, _ ->
          mousePos = change.position
      }
  ) {
      FragmentColor.init(this, renderer, target)
  }

}
